Advantage Environmental Lighting EM9 PAR-Type Lamp Head Emergency Unit
ILLUMINATION
Two fully adjustable 5.4W glare free PAR-type lamp heads.High performance chrome-plated metallized reflector and plastic lens for optimal light distribution.
ELECTRICAL
Dual 120/277 voltage. Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing. LVD (low voltage disconnect) prevents battery from deep discharge. 6V maintenance-free, rechargeable Sealed lead acid battery. Internal solid-state transfer switch automatically connects the internal battery to lamp heads for minimum 90-minute emergency illumination. Fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.
MOUNTING
Surface mount via easy connect back plate, which fits most standard junction boxes and snaps into place making internal electrical connections. Top and side knockout for conduit applications. Suitable for wall or ceiling mount.
HOUSING
Injection-molded, engineering-grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish.
OPTIONS
USA: Substantial transformation assembly in the U.S. complies with “AssembLED in the USA” under the Buy American Act
WARRANTY/LISTING
Five year warranty on all electronics and housing. Battery pro-rated for two years. Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes. UL listed for damp locations. (0°C – 50°C)
