Description
Advantage Environmental Lighting BAP Surface Ceiling Mount LED Luminaire
HOUSING
One-piece die-formed prime grade material as specified.Corners continuously seam welded and smooth with no post grinding (TIG). Clamshell housing resistant to penetration and contraband concealment.
BACK PLATE
Die-formed blade trap (1/4" minimum) prevents contrabandconcealment and access. Embossed standoffs prevent distortion.
FASTENERS
Hex head screws standard with option of torx head with center pin and allen head with center pin.
OPTICAL SYSTEM
High output LED’s available in 3000K, 3500K, 4000K, and 5000K. CRI >82. Vertically adjustable continuous “Z” brackets of prime grade material, secured to housing via thru-studs.
ELECTRICAL SYSTEM
Electronic drivers are available for 120/277V applications, 0-10v dimming standard. Long-life LED system rated for >100K life hours (L70 @ 50°C). Metal gear tray for internal LED driver. Complies with federal energy efficiency standards. Consult factory for special tuning to achieve specific lumen outputs.
MOUNTING
This fixture is designed for wall or ceiling mounting.
LISTINGS
UL and cUL Listed. Damp location rated. Wet Location optional.
WARRANTY
5-Year Limited Warranty.
IES Files
Click for BAP-40-M-BB16-B16-375P-125C-M.IES
