Advantage Environmental Lighting ISBA Indoor Sports High Durability Recessed/Recessed Flanged Troffer
The ISBA is a specification grade, high durability LED troffer designed for indoor sports applications such as racketball and squash. Available in 1x4, 2x2, and 2x4 housings. Integral grill with inner/outer lenses, or dual lensed only model.
CONSTRUCTION
Seam-welded and ground smooth construction. Various housing and doorframe material options are available. Inset doorframe available with or without integral grill. Doorframe attached to housing with stainless steel aircraft cables. Fixture maintains an IP65 rating and is sealed with closed-cell gaskets. Stainless steel Phillips head hardware secures doorframe to housing, Torx head with center-pin fasteners available. White-TGIC polyester powder-coating standard.
FINISH
Matte white finish standard for all painted housing/doorframe options.
LENS
High impact clear polycarbonate outer lens in specified thickness, with choice of diffusing inner lens. Lens is sealed to doorframe. Lens secured with lens clamps engineered for maximum strength and durability.
ELECTRICAL SYSTEM
120-277V electronic driver 0-10V, 1% dimming standard. Long-life LED system rated for >100K hours (L70 @ 25°C). Complies with federal energy efficiency standards.
LISTINGS
IP65 rating. UL listed. Manufactured in the USA, BAA Compliant.
MOUNTING
Universal housing suitable for both recessed grid and recessed flanged applications. Adjustable 90° swing arm system included standard.
LED
80 CRI or 90 CRI LEDs available in 2700K, 3000K, 3500K, 4000K and 5000K. Life is >100,000 hours at 70% lumen maintenance.
WARRANTY
5-Year limited warranty.
