Description
Advantage Environmental Lighting LCDISL CCT/Wattage Selectable LED Center Basket
The LCDISL series is an LED center basket with selectable 3500K, 4000K, or 5000K color temperatures. Selectable wattage options allow quick changes to lumen output with the flip of a switch.
APPLICATIONS
The LCDISL Series is designed to be a high quality, energy efficient LED fixtures for use in hotel lobbies, offices, common areas, hospitals, museums, retail, schools, and professional business environments.
CONSTRUCTION
The fixture is constructed of a heavy gauge steel body. Housing embossed for maximum rigidity. Rounded side flanges for safe handling. Ballast Cover snaps into housing to cover ballast and wires. White polyester polymer finish with a minimum 93% reflectivity.
ELECTRICAL SYSTEM
Color temperature selectable in 3500K, 4000K, and 5000K. 0-10V dimming driver included standard. Long-life LED system rated for >50K life hours (L70 @ 25°C). Metal gear tray for internal LED driver. Complies with federal energy efficiency standards.
MOUNTING
The fixture can be recess mounted in a standard grid ceiling, or surface mounted with a surface mount shroud.
LISTINGS
Independently tested to IESNA LM-79 and LM-80 specifications. UL and cUL Listed. Damp location rated.
WARRANTY
5-Year Limited Warranty.
| LCDISL22SSM: 2 x 2 CCT/Wattage Selectable LED Center Basket 30W/35W/40W 3500K/4000K/5000K 100LM/W | LCDISL24SSM: 2 x 4 CCT/Wattage Selectable LED Center Basket 30W/40W/50W 3500K/4000K/5000K 100LM/W |
