Advantage Environmental Lighting LISD Reflector LED Strip-light
The LISD is a narrow strip-light with focused a reflector .This high quality luminaire has a narrow design that makes it an ideal choice for industrial application.The reflector is offered in two different versions - standard or high lumen models and are produced from either specular or white material.
APPLICATIONS
The LISDSeries of Commercial LED Strips were designed to be high quality, energy efficient LED fixtures for use in commercial applications, offices, government facilities, schools, public areas, and industrial lighting applications.
CONSTRUCTION
Channel is die formed cold rolled steel with numerous KOs for ease of installation.Groove for Tong Hanger .End plate quickly converts to snap-in channel connector for continuous raw alignment. Channel /wireway cover secured with sheet metal screw.
OPTICAL SYSTEM
Reflector available in either specular or white material.
ELECTRICAL SYSTEM
Electronic drivers are available for 120/277V applications. Long-life LED system rated for >100K life hours (L70 @ 25°C). Metal gear tray for internal LED driver. Complies with Federal energy efficiency standards.
MOUNTING
Surface or pendant mount, individually or in continuous rows. Sufficient knockouts are provided. Double KO access on 4 ft and longer to facilitate wiring of units for multiple configurations.
LISTINGS
UL and cUL Listed. Damp location rated.
WARRANTY
5-Year Limited Warranty.
IES Files
Click for LISD2-40-ML-RS-M.IES
Click for LISD2-40-ML-RW-M.IES
Click for LISD4-40-MM-RS-M.IES
Click for LISD4-40-MM-RW-M.IES
