Advantage Environmental Lighting LSCDRSL CCT/Wattage Selectable LED Covered Strip
The LSCDRSL series is an LED covered strip with selectable 3500K, 4000K, or 5000K color temperatures. Selectable wattage options allow quick changes to lumen output with the flip of a switch.
APPLICATIONS
The LSCDRSL Series is designed to be a high quality, energy efficient LED fixtures for use in hotel lobbies, offices, common areas, hospitals, museums, retail, schools, and professional business environments.
CONSTRUCTION
The fixture is constructed of heavy gauge steel. White polyester polymer finish with a minimum 93% reflectivity. Anti-UV frosted polycarbonate lens provides uniform illumination with no visible LED pixelation.
ELECTRICAL SYSTEM
Color temperature selectable in 3500K, 4000K, and 5000K. 0-10V dimming driver included standard. Long-life LED system rated for >75K life hours (L70 @ 25°C). Power factor > 0.90. CRI >80. Total harmonic distortion < 20. Complies with federal energy efficiency standards. Working temperature -22F to 140F.
MOUNTING
Easy installation in new construction or retrofit as surface mount.
LISTINGS
Independently tested to IESNA LM-79 and LM-80 specifications. UL and cUL Listed. Damp location rated. IP40 rated. DLC Premium listed.
WARRANTY
5-Year Limited Warranty.
| LSCDRSL4SSM: 4' LED CCT/Wattage Selectable Covered Strip Luminaire 3500K/4000K/5000K 30W/35W/40W MV 120-277V | LSCDRSL8SSM: 8' LED CCT/Wattage Selectable Covered Strip Luminaire 3500K/4000K/5000K 30W/40W/50W MV 120-277V |
