Advantage Environmental Lighting LTCWL Lens Side Wet Location LED Troffer
The LTCWL Series is a Lens Side Wet Location LED Troffer available in 1x4, 2x2, and 2x4 body sizes. It was designed for recessed, wet location applications, and can be used as a budget clean room solution for certain applications. The lens is sealed to the housing to prevent particles from entering the facility. The housing is not sealed. Multiple lensing options are available, including inverted lens.
APPLICATIONS
The LTCWL Series of Lens Side Wet Location LED Troffers were designed to be high quality, energy efficient fixtures for use in wet location environments and budget clean room environments. Most commonly used in cafeterias, kitchens, and food processing facilities where light fixtures need to be sprayed down.
CONSTRUCTION
The fixture is constructed of a heavy gauge steel body. Housing embossed for maximum rigidity. Die-formed flat steel door with mitered corners. Belly pan snaps into housing to cover driver and wires. Neoprene gasket and silicone around the lens (inverted lens options available) to create a wet location fixture from the lens side down. The top of the housing is not sealed.
OPTICAL SYSTEM
White polyester polymer finish with a minimum 93% reflectivity. A variety of lensing options are available, with inverted lens options.
ELECTRICAL SYSTEM
Electronic drivers are available for 120/277V applications. Long-life LED system rated for >100K life hours (L70 @ 45°C). Metal gear tray for internal LED driver. Complies with federal energy efficiency standards.
MOUNTING
The fixture can be recess mounted in a standard grid ceiling.
LISTINGS
UL and cUL Listed. Wet location rated for room side of fixture.
WARRANTY
5-Year Limited Warranty.
Specification
| Input Voltage | 120/277VAC |
| Input Power | 33 - 179 Watts |
| Input Frequency | 50/60 Hz |
| CRI | 82 (minimum) |
| Operating Ambient Temperature Range (Ta) | -30° to 50° C |
| Lumen Output | 4650 - 25000 Lumens |
| Standard dimmimg control | 0-10V |
| CCT | 3000, 3500, 4000, 5000 Kelvin |
| Life time rating | 100,000 hrs @ L70 |
| Power factor | >0.9 |
| LTCWL140SLAM: 1X4 Recessed Wet Location Troffer Luminaire 33W 4650L 4000K | LTCWL140MLAM: 1X4 Recessed Wet Location Troffer Luminaire 57W 7974L 4000K | LTCWL140HLAM: 1X4 Recessed Wet Location Troffer Luminaire 80W 11150L 4000K | LTCWL240SLAM: 2X2 Recessed Wet Location Troffer Luminaire 33W 4650L 4000K | LTCWL240MLAM: 2X2 Recessed Wet Location Troffer Luminaire 57W 7974L 4000K | LTCWL240HLAM: 2X2 Recessed Wet Location Troffer Luminaire 80W 11150L 4000K |
| LTCWL440SLAM: 2X4 Recessed Wet Location Troffer Luminaire 33W 4650L 4000K | LTCWL440MLAM: 2X4 Recessed Wet Location Troffer Luminaire 57W 7974L 4000K | LTCWL440HLAM: 2X4 Recessed Wet Location Troffer Luminaire 80W 11150L 4000K | LTCWL440SMAM: 2X4 Recessed Wet Location Troffer Luminaire 86W 12040L 4000K | LTCWL440MMAM: 2X4 Recessed Wet Location Troffer Luminaire 93W 13016L 4000K | LTCWL440HMAM: 2X4 Recessed Wet Location Troffer Luminaire 112W 15728L 4000K |
| LTCWL440SHAM: 2X4 Recessed Wet Location Troffer Luminaire 118W 16500L 4000K | LTCWL440MHAM: 2X4 Recessed Wet Location Troffer Luminaire 143W 20000L 4000K | LTCWL440HHAM: 2X4 Recessed Wet Location Troffer Luminaire 179W 25000L 4000K |
IES Files
Click for LTCWL1-35-SL-A12-M.IES
