Description
Advantage Environmental Lighting MEP LED Recessed Patient Room
MEP offers both Reading and ambient lighting in a beautifully designed fixture. The MEP features innovative optical technology which provides powerful, focused illumination for examinations. Its exemplary design directs the light onto the bed and provides glare-free illumination for both the medical professional and patient. This ergonomical styled design helps bring a relaxed, comfortable feel to any patient room.
ELECTRICAL SYSTEM
Electronic drivers are available for 120/277V applications, 0-10v 1% dimming driver standard. Long-life LED system rated for 100K life hours (L70 @ 25°C). Metal gear tray for internal LED driver. Complies with federal energy efficiency standards. Reading, ambient, and reading come standard
OPTICAL SYSTEM
Reading: Linear, Extruded Satin side lenses. 0.100” thick on ends; prisms are located on the inside for easy cleaning. Various Ambient light lensing options are available, contact factory for additional customized options.
LISTINGS
UL Listed. Damp location UL rated. Wet location optional.
HOUSING
20 gauge steel, powder coat painted matte white electrostatically applied, powder coat finish. Optional anti-microbial finish, matte white.
LED
LEDs available in 2700K, 3000K, 4000K and 5000K with CRI > 80. Projected life is 100,000 hours at 70% lumen maintenance. 90 CRI available.
WARRANTY
5 - Year Limited Warranty.
DOORFRAME GASKET
One-piece closed cell silicone gasket seals door frame to housing. (optional with wet location option)
HOUSING FLANGE
Flange kit available per request.
