Advantage Environmental Lighting SB Fluorescent Strip
The SB Series is a Fluorescent Strip available in 1’ thru 8’ body lengths. It was designed for surface or suspended mounting applications.
APPLICATIONS
The SB Series of Fluorescent Strips were designed to be high quaility, energy effiecient fluorescent fixtures for use in commercial applications, offices, government facilities, schools, and public areas.
CONSTRUCTION
The fixture is contructed of a heavy gauge cold rolled steel body.
OPTICAL SYSTEM
White polyester polymer finish with a high reflectivity.
ELECTRICAL SYSTEM
120-277V electronic program start ballasts. 50-60 Hz operation. Sound rated A. Thermally protected. Automatic resetting Class P. High Power Factor. Non PCB.
MOUNTING
Surface or pendant mount, individually or in continuous rows. Sufficient knockouts are provided. Double KO access on 4 ft and longer to facilitate wiring of units for multiple ballast configurations.
LISTINGS
UL and cUL Listed. Indoor use only.
WARRANTY
1-Year Limited Warranty.
