Advantage Environmental Lighting WHB Wash Down High Bay Luminaire
The WHB Series is an IP Rated Wash Down Fluorescent High Bay, gasketed enclosure that is completely dust and moisture resistant. The WHB utilizes state-of-the-art fluorescent technology to deliver the highest possible efficiency in the lighting industry.
APPLICATIONS
The WHB Series of Wash Down High Bays were designed to be high quality, energy efficient fluorescent fixtures for use in food processing facilities, kitchens, parking garages, canopy, stair well car washes, government facilities, schools, public areas and industrial facilities. Suitable for both indoor and outdoor applications.
CONSTRUCTION
The fixture is constructed of a single-piece polycarbonate upper body and an acrylic diffuser securely positioned in a permanent, poured-in-place, polyurethane sealing gasket. The diffuser and upper components are locked in place and sealed tightly with tamper-resistant stainless steel retaining latches. High impact acrylic/DR material diffuser composition.
OPTICAL SYSTEM
White polyester polymer finish with a minimum 93% reflectivity. Miro 4 reflector available.
ELECTRICAL SYSTEM
Standard 120-277V electronic instant start ballasts for T8 lamping, ≤10% THD. For T8 fixtures utilizing a motion sensor, a Program Start ballast is required (see Options). 50-60 Hz operation. Sound rated A. Thermally protected. Automatic resetting Class P. High Power Factor. Non PCB.
MOUNTING
The fixture can be suspended or surface mounted. Utilizes off the shelf 1/2” fittings.
LISTINGS
UL and cUL Listed. CSA approved. NSF International Certified. IP66 and IP67 Certified for Wet Location applications. NEMA 4X.
WARRANTY
3-Year Limited Warranty.
