Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination.
Fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.
MOUNTING
Mounting canopy included for top or end mount.
Universal K/O pattern on back plate for wall mount.
HOUSING
Durable, powder-coated 20-gauge steel construction in white or black finish.
Unique design allows double face conversion in the field.
Field selectable steel knockout Chevron directional indicators.
OPTIONS
SDT: Self-diagnostic test feature performs monthly, biannually, and annually tests to ensure reliable operation and to meet electrical and life safety codes.
USA: Substantial transformation assembly in the U.S. complies with “AssembLED in the USA” under the Buy American Act.
WARRANTY/LISTING
Five year warranty on all electronics and housing. Battery pro-rated for five years.
Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination.
Fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.
MOUNTING
Mounting canopy included for top or end mount.
Universal K/O pattern on back plate for wall mount.
HOUSING
Durable, powder-coated 20-gauge steel construction in white or black finish.
Unique design allows double face conversion in the field.
Field selectable steel knockout Chevron directional indicators.
OPTIONS
SDT: Self-diagnostic test feature performs monthly, biannually, and annually tests to ensure reliable operation and to meet electrical and life safety codes.
USA: Substantial transformation assembly in the U.S. complies with “AssembLED in the USA” under the Buy American Act.
WARRANTY/LISTING
Five year warranty on all electronics and housing. Battery pro-rated for five years.
Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
