Double face utilizes factory installed silver or white mylar background panel.
ELECTRICAL
Dual 120/277 voltage standard.
Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.
4.8V long life, maintenance-free, rechargeable NiCd battery (EM models only).
Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination.
Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.
MOUNTING
Compatible with drywall or drop ceiling mount installations. Bar hangers included.
Wall mount capability optional.
HOUSING
Premium-grade, extruded aluminum housing.
Extruded aluminum trim assembly is easily detachable from below, providing accessibility for service or maintenance. Available in optional black or white powder-coated finishes.
Self-adhesive Chevron appliques and guide template provided for directional indication.
OPTIONS
WM: Allows for the unit to be wall recessed mounted.
2C-120V/2C-277V: Voltage-specific dual circuit option on the AC-only unit enables it to be connected to two different supplies at the same time.
SDT: Self-diagnostic feature performs monthly, biannual, and annual tests to ensure reliable operation and meets electrical and life safety codes.
USA: Substantial transformation assembly in the U.S. complies with “Assembled in the USA” under the Buy American Act.
SPV: UL Listed for 208/220/240 Volt, 50/60Hz. .
Custom: Signs available with requested ‘special’ wording
WARRANTY / LISTING
Five year warranty on all electronics and housing. Battery prorated for five years.
Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
