Hadco Urban Westbrooke LED Pendant Comfort (CXF14C)
Hadco Urban Westbrooke LED Pendant Comfort (CXF14C)
Roll over image to zoom in Click on image to zoom
Hadco Urban Westbrooke LED Pendant Comfort (CXF14C)Hadco Urban Westbrooke LED Pendant Comfort (CXF14C)

Hadco Urban Westbrooke LED Pendant Comfort (CXF14C)

Hadco UrbanSKU: HADCO-CXF14C
Price:
$0.00 USD

Fast & Easy Quote Request For Hadco Urban Lighting

Select the product options and the quantity and then click the “Request A Quote” button. If you do not see the option you want, note that on the request form. You may include your lighting fixtures list and attach files.
We will contact you with any questions and strive to provide you with a competitive quote as quickly as possible.

Description

Hadco Urban Westbrooke LED Pendant Comfort (CXF14C)

Product Family Details

Hadco Westbrooke pendant luminaires offer a simple and modern look but still traditional, providing style and performance to work in several urban applications including residential streets, city streets, campuses, parking lots and retail centers. These pendants are now available with comfort optics, providing a low glare solution for pedestrian applications.

Benefits

  • Comfort optics provide low glare solution to improve visual comfort
  • Offers a variety of optical distributions suitable for several applications
  • Ensures lasting durability and reliability
  • Significant energy savings over HID
  • Dimming controls available for additional energy savings during off-peak hours

Features

  • Comfort optics reduce glare
  • Multiple lumen packages
  • Side arm, top arm and wall mounting options available
  • Cast aluminum housing
  • IP66 rated optical chamber and LED driver

Applications

  • Road and Street
  • Bridges, Monuments, Facades
Product Name SKU Watts Lumens Kelvin
Westbrooke LED Pendant, Comfort Optics, 140LED, 450mA, 21W, Type 1, 3000K - 106.19 lm/W CXF14C-140-G1-1-730-4 21.2 2230
Westbrooke LED Pendant, Comfort Optics, 140LED, 650mA, 30W, Type 1, 3000K - 104 lm/W CXF14C-140-G1-1-730-6 30.4 3120
Westbrooke LED Pendant, Comfort Optics, 140LED, 1150mA, 52W, Type 1, 3000K - 102.1 lm/W CXF14C-140-G1-1-730-11 52.2 5309
Westbrooke LED Pendant, Comfort Optics, 140LED, 1675mA, 75W, Type 1, 3000K - 97.23 lm/W CXF14C-140-G1-1-730-16 75 7292
Westbrooke LED Pendant, Comfort Optics, 140LED, 2100mA, 94W, Type 1, 3000K - 94.12 lm/W CXF14C-140-G1-1-730-21 94 8847
Westbrooke LED Pendant, Comfort Optics, 140LED, 450mA, 21W, Type 2, 3000K - 106 lm/W CXF14C-140-G1-2-730-4 21.2 2226
Westbrooke LED Pendant, Comfort Optics, 140LED, 650mA, 30W, Type 2, 3000K - 96.87 lm/W CXF14C-140-G1-2-730-6 30.4 2906
Westbrooke LED Pendant, Comfort Optics, 140LED, 1150mA, 52W, Type 2, 3000K - 95.12 lm/W CXF14C-140-G1-2-730-11 52.2 4946
Westbrooke LED Pendant, Comfort Optics, 140LED, 1675mA, 75W, Type 2, 3000K - 90.56 lm/W CXF14C-140-G1-2-730-16 75 6792
Westbrooke LED Pendant, Comfort Optics, 140LED, 2100mA, 94W, Type 2, 3000K - 87.68 lm/W CXF14C-140-G1-2-730-21 94 8242
Westbrooke LED Pendant, Comfort Optics, 140LED, 450mA, 21W, Type 3, 3000K - 108.81 lm/W CXF14C-140-G1-3-730-4 21.2 2285
Westbrooke LED Pendant, Comfort Optics, 140LED, 650mA, 30W, Type 3, 3000K - 99.43 lm/W CXF14C-140-G1-3-730-6 30.4 2983
Westbrooke LED Pendant, Comfort Optics, 140LED, 1150mA, 52W, Type 3, 3000K - 97.63 lm/W CXF14C-140-G1-3-730-11 52.2 5077
Westbrooke LED Pendant, Comfort Optics, 140LED, 1675mA, 75W, Type 3, 3000K - 92.96 lm/W CXF14C-140-G1-3-730-16 75 6972
Westbrooke LED Pendant, Comfort Optics, 140LED, 2100mA, 94W, Type 3, 3000K - 90 lm/W CXF14C-140-G1-3-730-21 94 8460
Westbrooke LED Pendant, Comfort Optics, 140LED, 450mA, 21W, Type 4, 3000K - 117.48 lm/W CXF14C-140-G1-4-730-4 21.2 2467
Westbrooke LED Pendant, Comfort Optics, 140LED, 650mA, 30W, Type 4, 3000K - 107.37 lm/W CXF14C-140-G1-4-730-6 30.4 3221
Westbrooke LED Pendant, Comfort Optics, 140LED, 1150mA, 52W, Type 4, 3000K - 105.4 lm/W CXF14C-140-G1-4-730-11 52.2 5481
Westbrooke LED Pendant, Comfort Optics, 140LED, 1675mA, 75W, Type 4, 3000K - 100.37 lm/W CXF14C-140-G1-4-730-16 75 7528
Westbrooke LED Pendant, Comfort Optics, 140LED, 2100mA, 94W, Type 4, 3000K - 97.17 lm/W CXF14C-140-G1-4-730-21 94 9134
Westbrooke LED Pendant, Comfort Optics, 140LED, 450mA, 21W, Type 5, 3000K - 106.81 lm/W CXF14C-140-G1-5-730-4 21.2 2243
Westbrooke LED Pendant, Comfort Optics, 140LED, 650mA, 30W, Type 5, 3000K - 104.6 lm/W CXF14C-140-G1-5-730-6 30.4 3138
Westbrooke LED Pendant, Comfort Optics, 140LED, 1150mA, 52W, Type 5, 3000K - 102.69 lm/W CXF14C-140-G1-5-730-11 52.2 5340
Westbrooke LED Pendant, Comfort Optics, 140LED, 1675mA, 75W, Type 5, 3000K - 97.79 lm/W CXF14C-140-G1-5-730-16 75 7334
Westbrooke LED Pendant, Comfort Optics, 140LED, 2100mA, 94W, Type 5, 3000K - 94.67 lm/W CXF14C-140-G1-5-730-21 94 8899
Westbrooke LED Pendant, Comfort Optics, 140LED, 450mA, 21W, Type 1, 4000K - 106.19 lm/W CXF14C-140-G1-1-740-4 21.2 2230
Westbrooke LED Pendant, Comfort Optics, 140LED, 650mA, 30W, Type 1, 4000K - 104 lm/W CXF14C-140-G1-1-740-6 30.4 3120
Westbrooke LED Pendant, Comfort Optics, 140LED, 1150mA, 52W, Type 1, 4000K - 102.1 lm/W CXF14C-140-G1-1-740-11 52.2 5309
Westbrooke LED Pendant, Comfort Optics, 140LED, 1675mA, 75W, Type 1, 4000K - 97.23 lm/W CXF14C-140-G1-1-740-16 75 7292
Westbrooke LED Pendant, Comfort Optics, 140LED, 2100mA, 94W, Type 1, 4000K - 94.12 lm/W CXF14C-140-G1-1-740-21 94 8847
Westbrooke LED Pendant, Comfort Optics, 140LED, 450mA, 21W, Type 2, 4000K - 106 lm/W CXF14C-140-G1-2-740-4 21.2 2226
Westbrooke LED Pendant, Comfort Optics, 140LED, 650mA, 30W, Type 2, 4000K - 96.87 lm/W CXF14C-140-G1-2-740-6 30.4 2906
Westbrooke LED Pendant, Comfort Optics, 140LED, 1150mA, 52W, Type 2, 4000K - 95.12 lm/W CXF14C-140-G1-2-740-11 52.2 4946
Westbrooke LED Pendant, Comfort Optics, 140LED, 1675mA, 75W, Type 2, 4000K - 90.56 lm/W CXF14C-140-G1-2-740-16 75 6792
Westbrooke LED Pendant, Comfort Optics, 140LED, 2100mA, 94W, Type 2, 4000K - 87.68 lm/W CXF14C-140-G1-2-740-21 94 8242
Westbrooke LED Pendant, Comfort Optics, 140LED, 450mA, 21W, Type 3, 4000K - 108.81 lm/W CXF14C-140-G1-3-740-4 21.2 2285
Westbrooke LED Pendant, Comfort Optics, 140LED, 650mA, 30W, Type 3, 4000K - 99.43 lm/W CXF14C-140-G1-3-740-6 30.4 2983
Westbrooke LED Pendant, Comfort Optics, 140LED, 1150mA, 52W, Type 3, 4000K - 97.63 lm/W CXF14C-140-G1-3-740-11 52.2 5077
Westbrooke LED Pendant, Comfort Optics, 140LED, 1675mA, 75W, Type 3, 4000K - 92.96 lm/W CXF14C-140-G1-3-740-16 75 6972
Westbrooke LED Pendant, Comfort Optics, 140LED, 2100mA, 94W, Type 3, 4000K - 90 lm/W CXF14C-140-G1-3-740-21 94 8460
Westbrooke LED Pendant, Comfort Optics, 140LED, 450mA, 21W, Type 4, 4000K - 117.48 lm/W CXF14C-140-G1-4-740-4 21.2 2467
Westbrooke LED Pendant, Comfort Optics, 140LED, 650mA, 30W, Type 4, 4000K - 107.37 lm/W CXF14C-140-G1-4-740-6 30.4 3221
Westbrooke LED Pendant, Comfort Optics, 140LED, 1150mA, 52W, Type 4, 4000K - 105.4 lm/W CXF14C-140-G1-4-740-11 52.2 5481
Westbrooke LED Pendant, Comfort Optics, 140LED, 1675mA, 75W, Type 4, 4000K - 100.37 lm/W CXF14C-140-G1-4-740-16 75 7528
Westbrooke LED Pendant, Comfort Optics, 140LED, 2100mA, 94W, Type 4, 4000K - 97.17 lm/W CXF14C-140-G1-4-740-21 94 9134
Westbrooke LED Pendant, Comfort Optics, 140LED, 450mA, 21W, Type 5, 4000K - 106.81 lm/W CXF14C-140-G1-5-740-4 21.2 2243
Westbrooke LED Pendant, Comfort Optics, 140LED, 650mA, 30W, Type 5, 4000K - 104.6 lm/W CXF14C-140-G1-5-740-6 30.4 3138
Westbrooke LED Pendant, Comfort Optics, 140LED, 1150mA, 52W, Type 5, 4000K - 102.69 lm/W CXF14C-140-G1-5-740-11 52.2 5340
Westbrooke LED Pendant, Comfort Optics, 140LED, 1675mA, 75W, Type 5, 4000K - 97.79 lm/W CXF14C-140-G1-5-740-16 75 7334
Westbrooke LED Pendant, Comfort Optics, 140LED, 2100mA, 94W, Type 5, 4000K - 94.67 lm/W CXF14C-140-G1-5-740-21 94 8899
Product Files

Click forCXF14C/CXF15C Westbrooke LED pendant comfort pendant - Spec Sheet

Click forPLt-18107 Comfort Optics Brochure

Click forCXF14 & CXF15 Top Mount Fixtures - Instructions
