Lumiere LightingSKU: 1003-A1-RCS-RI-LED2790-M-WT-L2-UNV-RSM

Type: 1003-A1-RCS-RI-LED2790-M-WT-L2-UNV-RSM

Variant

Price:

$9,999.00 USD

Quantity:

Share this product

Select the product options and the quantity and then click the “Request A Quote” button. If you do not see the option you want, note that on the request form. You may include your lighting fixtures list and attach files.
We will contact you with any questions and strive to provide you with a competitive quote as quickly as possible.

Lumiere Lanterra 1003 - A1 (1 Head) LED Accent and Flood Light

Lanterra 1003-A1 (one head) is a 3.25" O.D., linevoltage Accent Flood light with dimmable LED. It is available with adjustable rear center swivel with lock rotation providing 180 degree tilt and 340 degree rotation. The luminaire comes with various mounting,beam optics. It also comes with various lens, louvers and colors or dichroic filters which can combine upto two at once to create multiple lighting effects. The fixture may be used indoors or outdoors and carries IP66 rating.

Features

Single and dual head, 180 degree tilt and 340 degree rotation
Up to 1900 delivered lumens and 103 Lm/W
Spot, Medium, Flood and Wide optics, Field interchangeable
Premium machined aluminum, brass, bronze, copper or stainless steel
Line voltage. ELV, Triac and 0-10V std. dimming
Holds up to 2 accessories (lens, louver, filters)
Integral and remote driver mounting options. Stainless steel hardware
Stand-alone integral sensor option

Product Files

Click forLumiere Lanterra 1003 specification sheet

Click forLumiere Lanterra Brochure

Click forLumiere Lanterra MB Installation Instructions (Ground Mount Recessed Box)

Click forLumiere Lanterra RSM Installation Instructions (Round Surface Mount)

Click forLumiere Lanterra WIS Installation Instructions

Click forLumiere Lanterra WRx Installation Instructions (Remote driver housing - Round Wall or Round Square)

We deliver worldwide

Your shipping service or ours

Project quotes

Competitive project quotations

Top-notch support

Personal expert service

Secure payments

The latest payment technologies

Description
Product Files
Lumiere Transformers
Lumiere Warranty

Description

Lumiere Lanterra 1003 - A1 (1 Head) LED Accent and Flood Light

Lanterra 1003-A1 (one head) is a 3.25" O.D., linevoltage Accent Flood light with dimmable LED. It is available with adjustable rear center swivel with lock rotation providing 180 degree tilt and 340 degree rotation. The luminaire comes with various mounting,beam optics. It also comes with various lens, louvers and colors or dichroic filters which can combine upto two at once to create multiple lighting effects. The fixture may be used indoors or outdoors and carries IP66 rating.

Features

Single and dual head, 180 degree tilt and 340 degree rotation
Up to 1900 delivered lumens and 103 Lm/W
Spot, Medium, Flood and Wide optics, Field interchangeable
Premium machined aluminum, brass, bronze, copper or stainless steel
Line voltage. ELV, Triac and 0-10V std. dimming
Holds up to 2 accessories (lens, louver, filters)
Integral and remote driver mounting options. Stainless steel hardware
Stand-alone integral sensor option

Product Files

Click forLumiere Lanterra 1003 specification sheet

Click forLumiere Lanterra Brochure

Click forLumiere Lanterra MB Installation Instructions (Ground Mount Recessed Box)

Click forLumiere Lanterra RSM Installation Instructions (Round Surface Mount)

Click forLumiere Lanterra WIS Installation Instructions

Click forLumiere Lanterra WRx Installation Instructions (Remote driver housing - Round Wall or Round Square)

Lumiere Transformers

Product Files

Click for Lumiere Low Voltage & Transformers Information

Lumiere Warranty

Cooper Lighting Outdoor LED Products.

Addendum to Standard Terms and Conditions of Sale.

Subject to all of the limitations set forth in Cooper Lighting’s Terms and Conditions of Sale, for Cooper Lighting Outdoor Light Emitting Diode (LED) luminaires only, Cooper Lighting warrants to the original purchaser that the factory-installed electrical system will be free from defects in material and workmanship for 5 years from the date of shipment of the products. If 10% of the individual LEDs (light sources) should fail within 5 years of shipment, Cooper will, at its sole option, ship a repaired or replacement fixture EXW (Incoterms 2000) Cooper’s factory. The warranty does not cover failures due to abnormal site conditions. These abnormal conditions include, but are not limited to, under/over voltage, under/over current, excessive switching and excessive ambient temperatures.

Subject to all of the limitations set forth in Cooper Lighting’s Terms and Conditions of Sale, for Cooper Lighting Outdoor Light Emitting Diode (LED) luminaires only, Cooper Lighting warrants to the original purchaser finish for a period of 5 years from date of shipment. Cooper will, at its sole option, repair or replace the defective finish if it exhibits cracking, peeling, excessive fading or corrosion defects during the warranty period. During the warranty period some fading, staining or chalking may occur. This is normal aging for the finish used, is not a manufacturing defect, and is not covered by our warranty.
