Description
Arms are a tapered elliptical design made of 6063 alloy extruded aluminum tube with 2-3/8" OD luminaire end. The arm is joined to the attachment system by a continuous circumferential weld. All arms have a 32" rise.
These brackets are typically purchased for use on an existing pole, can be mounted to the side of a structure or building, or used in conjunction with a wood pole.
| Catalog Number | Arm Span | Effective Projected Area | Lumiere Weight (lb) | Wind Speed | Gust | Cutsheet |
|---|---|---|---|---|---|---|
| TEA-4A | 4' | 2.5 Max | 50 Max | 90 Max | 117 Max | View |
| TEA-6A | 6' | 2.5 Max | 50 Max | 90 Max | 117 Max | View |
| TEA-8A | 8' | 2.5 Max | 50 Max | 90 Max | 117 Max | View |
| TEA-10A | 10' | 2.5 Max | 50 Max | 90 Max | 117 Max | View |
While we don’t have specific foundation details for light poles, these are typically determined by a local electrical engineer or the manufacturer's representative, as they depend on factors like soil conditions and local regulations. Once you've selected the pole you need, please provide us with the brand name, complete SKU, and quantity. We'd be happy to assist you further with a detailed quote.
